Oil Mist Traps

>
Products
>
Oil Mist Traps

In low vacuum section between the atmospheric pressure (760 Torr) and 10 Torr, since the amount of air sucked into the vacuum pump is large, the phenomenon that the vacuum oil is discharged with the air as a fine mist from the exhaust port will occur. This is referred to as the oil mist and OMT is the exhaust filter that is used in case you can’t connect the exhaust line to a separate hood and duct, or external.

WOF-150(PC)

Specifications


Inlet/Outlet	NW25/NW25
Material	Poly Carbonate (PC)
Weight	0.38kg
Filter Spare for replacement	OMT Filter for WOF-150
Applicable Pumps	W2V10 ~ W2V40

WOF-150(Metal)

Specifications


Inlet/Outlet	NW25/NW25
Material	Aluminum
Weight	1.1kg
Filter Spare for replacement	OMT Filter for WOF-150
Applicable Pumps	W2V10 ~ W2V40

WOF-200(Metal)

Specifications


Inlet/Outlet	NW25/NW25
Material	Iron
Weight	1kg
Filter Spare for replacement	OMT Filter for WOF-200
Applicable Pumps	W2V10 ~ W2V40

WOF-250(PA)

Specifications


Inlet/Outlet	NW40/NW40
Material	Poly Amide 6/6 (Nylon)
Weight	1.45kg
Filter Spare for replacement	OMT Filter for WOF-250
Applicable Pumps	W2V60 ~ W2V80

WOF-350(Metal)

Specifications


Inlet/Outlet	1 1/4” / 1 1/4"
Material	Iron
Weight	2kg
Filter Spare for replacement	OMT Filter for WOF-350
Applicable Pumps	W2V60 ~ W2V150

WOF-450(Metal)

Specifications


Inlet/Outlet	2” / 2”
Material	Iron
Weight	7kg
Filter Spare for replacement	OMT Filter for WOF-450
Applicable Pumps	W2V180
