WMT-250/400

•
•

Specifications

Inlet/Outlet (250, 400)	NW25/NW25, NW40/NW40
Material : Case, An internal filter	Carbon Steel, Teflon Polyester
Weight	1kg
Filter Spare for replacement	Inner filter NW25 for WMT-250
	Inner filter NW40(소)/(대) for WMT-400
Applicable Pumps	WMT-250 : W2V10 ~ W2V40
	WMT-400 : W2V60 ~ W2V180

Outer dimension

Name	Product Description	Ordering Number	A	B	C	D	E
FORELINE MATERIAL TRAP	WMT-250	IFDFME220000	85	57	96	47	NW25
FORELINE MATERIAL TRAP	WMT-400	IFDFME440000	111	86	146	70	NW40

Angle Valve

•
•

Specifications

		NW25 (Common)	NW40 (Common)
Compressed Air (kg/cm 2 )		4~5	4~5
Conductance (ℓ/sec)		12	32
Operating pressure Range (Pa)	Metal Bellows	10 -8 to 3x10 5	10 -8 to 3x10 5
	O-ring	10 -6 to 3x10 5	10 -8 to 3x10 5
Leak Rate(Pa.ℓ/sec)	Metal Bellows	<1x10 -7	<1x10 -7
	O-ring	<1x10 -6	<1x10 -6
Sealing part(life-time)	Metal Bellows	200,000	200,000
	O-ring	80,000	80,000
Temperature Range(°C)		0 to 80	0 to 80
Connection Flange (ISO)		NW25	NW40
Weight(kg)		1.2	1.8

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	A	B	C	D	E
ANGLE VALVE	NW16 MANUAL BELLOWS	VVAMBL160000	54.6	109.9	141.6	155.5	NW16
ANGLE VALVE	NW25 MANUAL BELLOWS	VVAMBL250000	51.6	104.9	136	150.5	NW25
ANGLE VALVE	NW40 MANUAL BELLOWS	VVAMBL400000	61	129.5	160.5	178.5	NW40
ANGLE VALVE	NW16 MANUAL ORING	VVAMOR160000	54.6	109.9	141.6	155.5	NW16
ANGLE VALVE	NW25 MANUAL ORING	VVAMOR250000	51.6	104.9	136	150.5	NW25
ANGLE VALVE	NW40 MANUAL ORING	VVAMOR400000	61	129.5	160.5	178.5	NW40

*angle valve air type (air double ⁄ air single) downloaded the files on the cad, check.

Z-Line Valve

Please direct inquiries to headquarters.

Auto Vent Valve

•
•

Specifications

	Auto Vent Valve-NW25	Auto Vent Valve-NW40
Voltage	AC24V, 10~20mA	AC 100V, 25mA
Power(50/60Hz)	11W	6/4.2W
Connector	1/8 inch
Flange Size	NW25	NW40
Conductance(ℓ/sec)	15	45
Leak Rate(Torr-ℓ/sec)	Max. 1.0 x 10-9
Material:Body, Sealing	SUS304, Viton
Life Cycle	10,000 (Room Temperature)
Weight(kg)	1.8	2.8

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	A	B	C	D	E	F
AUTOVENT ANGLE VALVE	NW25/NW25	VVAVOR250000	45	84.5	155	65	94	NW25

Clamp

•
•

Specifications

Specification	NW16, NW25, NW40, NW50
Material	Aluminum
Applicable Pump	NW16 : W2V05, NW25 : W2V10~40
	NW40 : W2V60~180 / NW50 : NW50-Inlet/Outlet

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	D	d	H	T
Clamp	NW16	ACCCMA001610	42	20	61	17
Clamp	NW25	ACCCMA002510	52	30	73	17
Clamp	NW40	ACCCMA004010	70	44	90	17
Clamp	NW50	ACCCMA005010	94	62	123	17

Centering

•
•

Specifications

Specification	NW16, NW25, NW40, NW50
Material : metal ring, O-ring	STS304, NBR/VITON(Select)
Use	Specification of the same set and clamp

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	A	B	C	D
CENTER RING	NBR/NW16(ST304)	ACCCOORN1601	17	16	8	3.9
CENTER RING	NBR/NW25(ST304)	ACCCOORN2501	26	25	8	3.9
CENTER RING	NBR/NW40(ST304)	ACCCOORN4001	41	40	8	3.9
CENTER RING	NBR/NW50(ST304)	ACCCOORN5001	52	50	8	3.9

Hose Nipple

•
•

Specifications

Specification	NW25-∅12, NW25-∅16, NW25-∅26, NW40-∅36
Material	Aluminum(A2024)
Applicable Pumps	NW25 : W2V10~W2V40
	NW40 : W2V60~W2V150

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	A	B	C	D	E
Hose Nipple	NW25 - ∅12	ACHNMA251200	12	40	60	33	10.5
Hose Nipple	NW25 - ∅16	ACHNMA251600	16	40	60	35	10.5
Hose Nipple	NW25 - ∅26	ACHNMA252600	26	40	69	57	20
Hose Nipple	NW40 - ∅36	ACHNMA403600	36	55	68.5	55	20

PT Nipple

•
•

Specifications

Specification	Material	Spiral	Applicable Pumps
NW16-1/4”	SUS	Outside diameter	W2V05
NW25-1/4”	AL	Inside diameter	W2V10~W2V40
NW25-3/8”	AL	Inside diameter
NW25-1/2”	Zn(CR PLATED)	Inside diameter
NW25-3/4”	Zn(CR PLATED)	Outside diameter
NW25-1”	AL	Inside diameter
NW40-1&1/4”	SUS	Outside diameter	W2V60~W2V180

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	A	B	C	D	E
PT-Nipple	NW25-3/8”(AL/ID)	ACPNMA253800	13.8	40	26	35	3/8”
PT-Nipple	NW25-1/4” (AL/ID)	ACPNMA251400	10.5	40	26	35	1/4"
PT-Nipple	NW25-1” (AL/ID)	ACPNMA251000	24.8	40	40	45	1”
PT-Nipple	NW25-1/2”( ZINC/CR/ID)	ACPNMZ251200	18.5	40	32	26.5	1/2"
PT-Nipple	NW25-3/4” ( ZINC/CR/OD)	ACPNMZ253401	18.5	40	26	27	3/4”
PT-Nipple	NW16-1/4” (SUS/OD)	ACPNMS161401	8	29.4	20	35	1/4”
PT-Nipple	NW40-1&1/4” (SUS/OD)	ACPNMS401141	35	55	42	30	1 1/4"

Welding Flange

•
•

Specifications

Specification	NW16, NW25, NW40, NW50
Material	SUS(STS304)
Applicable Pumps	NW16 : W2V05
	NW25 : W2V10~W2V40
	NW40 : W2V60~W2V180
	NW50 : Pump or Pipe with NW50-Inlet/Outlet

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	A	B	C	D	E
WELDING FLANGE	NW16/15MM	ACFLMS161500	30	17.2	16	20	15
WELDING FLANGE	NW25/15MM	ACFLMS251500	40	26.2	24	28	15
WELDING FLANGE	NW40/15MM	ACFLMS401500	50	41.2	34	38	15
WELDING FLANGE	NW50/15MM	ACFLMS501500	75	52.2	51	57	15
WELDING FLANGE	NW16/30MM	ACFLMS163000	30	17.2	16	21.7	30
WELDING FLANGE	NW25/30MM	ACFLMS253000	40	26.2	24	27.2	30
WELDING FLANGE	NW40/30MM	ACFLMS403000	55	41.2	34	42.7	30
WELDING FLANGE	NW50/30MM	ACFLMS503000	75	52.2	51	57	30

Blank

•
•

Specifications

Specification	NW16, NW25, NW40, NW50
Material	SUS(STS304)
Applicable Pumps/Pipe	NW16 : W2V05
	NW25 : W2V10~W2V40
	NW40 : W2V60~W2V180
	NW50 : Pump or Pipe with NW50-Inlet/Outlet

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	A	B
BLANK	STS/NW16	ACBKMS001600	30	17.2
BLANK	STS/NW25	ACBKMS002500	40	26.2
BLANK	STS/NW40	ACBKMS004000	55	41.2
BLANK	STS/NW50	ACBKMS005000	75	52.2

Reducer

•
•

Specifications

Specification	NW25-NW16, NW40-NW25, NW50-NW40
Material	SUS(STS304)

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	A	B	C
REDUCER	NW25-NW16	ACREMS251600	40	30	40
REDUCER	NW40-NW25	ACREMS402500	55	40	40
REDUCER	NW50-NW40	ACREMS504000	75	55	40

Tee

•
•

Specifications

Specification	NW16, NW25, NW40, NW50
Material	SUS(STS304)

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	A	B	C	D
TEE	NW16	ACTEMI001600	40.4	80.8	30	17.2
TEE	NW25	ACTEMI002500	58.6	117.2	40	26.2
TEE	NW40	ACTEMI004000	77.6	155.2	55	41.2
TEE	NW50	ACTEMI005000	80	160	75	52.2

Cross

•
•

Specifications

Specification	NW16, NW25, NW40, NW50
Material	SUS(STS304)

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	A	B	C	D
CROSS	NW16	ACRMMI001600	40.4	80	30	17.2
CROSS	NW25	ACRMMI002500	58.6	117.2	40	26.2
CROSS	NW40	ACRMMI004000	77.6	155.2	55	41.2
CROSS	NW50	ACRMMI005000	80	160	75	52.2

Elbow

•
•

Specifications

Specification	NW16, NW25, NW40, NW50
Material	SUS(STS304)

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	A	B	C
ELBOW	NW16	ACELMI001600	53.1	30	17.2
ELBOW	NW25	ACELMI002500	68.1	40	26.2
ELBOW	NW40	ACELMI004000	77.6	55	41.2
ELBOW	NW50	ACELMI005000	70	75	52.2

Bellows

•
•

Specifications

Connection standard	NW16, NW25, NW40, NW50
Length	Up to 100 ~ 300MM, 50MM unit,
	Up to 300 ~ 1000MM, 100MM units
	Length adjustable in 500MM increments from 1000 to 2000MM
Material	SUS(STS304)

Outer dimension (unit : mm)

Name	Product Description	Ordering Number	A	B	C
BELLOWS	NW16X100~2000MM	ACBL01001600~ACBL20001600	100~2000	30	17.2
BELLOWS	NW25X100~2000MM	ACBL01002500~ACBL20002500	100~2000	40	26.2
BELLOWS	NW40X100~2000MM	ACBL01004000~ACBL20004000	100~2000	55	41.2
BELLOWS	NW50X250, 800MM	ACBL02505000, ACBL08005000	250, 800	75	52.2

Vacuum Hose

Specifications

Specification : Inside diameter	∅8, ∅13, ∅20, ∅32
Length	1,000MM single length
Material	RUBBER

(unit : mm)

Name	Product Description	Ordering Number	Inside diameter	Use NIPPLE Outside diameter
VACUUM HOSE	∅8X1000MM	ACVHUT081000	8	12
VACUUM HOSE	∅13X1000MM	ACVHUT131000	13	16
VACUUM HOSE	∅20X1000MM	ACVHUT201000	20	26
VACUUM HOSE	∅32X1000MM	ACVHUT301000	32	36

MR-200 (NEOVAC)

Specifications

		General Properties
ISO Viscosity Grade		68
Viscosity	40°C*mm 2 /s	71.0
Color	ASTM	L0.5
Density	15°C g/cm 3	0.883
Flash Point	°C	256
Pour Point	°C	-17.5
Total oxidation	mgKOH/g	0.00
Demulsibility		40-40-0 (Under5)
Vapor Pressure	50°C Pa	Below 1.3×10 -3
	50°C Torr	Below 1.0×10 -5

Sales Unit

1L, 20L

Fomblin 16/6

Specifications

Typical Property	Units	16/6
Average molecular weight	a.m.u.	2700
Specific gravity (20°C) (68°F)	40°C*mm 2 /s	71.0
Kinematic Viscosity	ASTM	L0.5
Viscosity Index	15°C g/cm 3	0.883
Vapor Pressure @ 25°C(68°F) @100°C(212°F)
	torr	2×10 -6
	torr	2×10 -4
Pour Point	°C	-45
	°F	-49
Heat of vaporization (200°C) (392°F)	cal/g	8
Surface Tension	dyne/cm	22
Evaporation loss(22hrs; 149°C)	% by wt.	3.9
Ultimate total pressure	torr	2.4×10 -3
Specific oil consumption	cm 3 /hr	0.5

Sales Unit

- Mainly sold by being filled in pump
- For more information, please contact us.
