Pirani Gauge

Pirani Gauge

Digital gauge with pirani method measures the range of 20 Torr ~ 1mTorr. It provides the measured vacuum data as graphs and excel file formats through a dedicated program.

Display Range	1mTorr~20Torr
Data Gathering Cycle	200ms
Power	20W, Ac85~260V, 60/50Hz

Specifications

Content	Description
Display Range	1mTorr ~ 20Torr
Error Range	15%
Display	FND, LED
Operation	Front 8 button type
Calibration	User can calibrate by using SPAN & ZERO dial
Set Point	Dual Set Point(High/Low Set Value) Relay Contact
Data Gathering Cycle	200ms
Digital Output	12bit output of current vacuum level
Monitoring Program	RS232C data transfer to PC program
ADC	12Bit
Sensor Type	15mm O.D. (standard)
Sensor Cable	2M (default length)
Power	20W, AC85 ~ 260V, 60/50Hz

Dimensions

Pirani Gauge Parts

Control Pannel

LED display by 0.1 point

Setting 2 set points for auto controlling

Torr/Pascal Unit Change
Sensor Cable

2m(default)

5m

10m

User request length
Gauge Adaptor(T)/(I)

NW25-15 phi Gauge Port

-NW25 / Venting

NW25-15 phi Gauge Port

/ Venting
Sensor

15mm O.D.(standard)

ISO KF(NW16)
